model number

working
voltage
(max)

breakdown
voltage

peak
current
(max)

clamping
voltage
(max)

energy
absorption
(max)

typical
capacitance

unit condition

ac
(vrms)

dc
(v)

1ma
(v)

8/20us
(a)

(a)

(v)

10/1000
(j)

1khz
(pf)

1206ml080m

4

5.5

8

150

1

17

0.3

4800

1206ml110m

6

8

11

200

1

25

0.4

3900

1206ml150k

8

11

15

200

1

30

0.5

2500

1206ml180k

11

14

18

200

1

33

0.5

1500

1206ml220k

14

18

22

200

1

42

0.5

1200

1206ml270k

17

22

27

200

1

48

0.6

1000

1206ml330k

20

26

33

200

1

54

0.7

800

1206ml390k

25

30

39

200

1

65

1.0

650

1206ml470k

30

38

47

200

1

77

1.1

380

1206ml560k

35

45

56

100

1

90

0.4

300

1206ml680k

40

56

68

100

1

110

0.5

180

1206ml820k

50

65

82

100

1

135

0.6

180

1206ml101k

60

85

100

100

1

146

0.7

150

notes:
1.tolerance of breakdown voltage:15~18=±15%,22~56v=±15% 。
2.tolerance of capacitance voltage:±20% 。
3.typical leakage at 25℃<50ua, maximum leakage 100ua 。
4.in order to satisfy the applications of customer in various fields, the capacitance range
※can be designed during manufacturing according
  to the request, please contact our sales department if needed 。

model

0402
(1005)

0603
(1608)

0805
(2012)

1206
(3216)

1210
(3225)

1812
(4532)

2220
(5750)

length(l)

1.00
±0.10

1.60
±0.15

2.00
±0.20

3.20
±0.20

3.20
±0.20

4.50
±0.20

5.70
±0.20

width(w)

0.50
±0.10

0.80
±0.10

1.25
±0.15

1.60
±0.15

2.50
±0.20

3.20
±0.20

5.00
±0.20

thickness(d)

0.50
±0.10

0.80
±0.10

1.20max

1.50max

1.50max

2.00max

2.50max
