0402贴片压敏电阻 -ag官网

model number

working
voltage
(max)

breakdown
voltage

peak
current(max)

clampingvoltage
(max)

energy
absorption(max)

typical
capacitance

unit condition

ac
(vrms)

dc
(v)

1ma
(v)

8/20us
(a)

(a)

(v)

10/1000
(j)

1khz
(pf)

0402ml050m

2.5

3.3

5

16

1

13

0.05

390

0402ml080m

4

5.5

8

20

1

19

0.05

295

0402ml120m

7

9

12

20

1

32

0.05

190

0402ml150m

8

11

15

20

1

33

0.05

160

0402ml180k

11

14

18

20

1

38

0.05

135

0402ml240k

14

18

24

20

1

45

0.05

93

0402ml270k

17

22

27

20

1

50

0.05

75

0402ml330k

20

26

33

20

1

60

0.05

54

0402ml390k

25

30

39

20

1

72

0.05

45

0402ml470k

30

38

47

20

1

85

0.05

40

notes:
1.tolerance of breakdown voltage:15~47=±10% 。
2.tolerance of capacitance voltage:±20% 。
3.typical leakage at 25℃<50ua, maximum leakage 100ua 。
4.in order to satisfy the applications of customer in various fields, the capacitance range
※can be designed during manufacturing according
  to the request, please contact our sales department if needed 。
