东洋dye温度保险丝
|
part number |
terminal type |
rated voltage |
rated current |
obtained safety standard |
rated functioning temperature(tf) |
holding temperature(th) |
maximum temperature (tm) |
|
|
axial |
max. 250v |
max.1 |
pse, ek |
280℃ |
230℃ |
350℃ |
|
|
axial |
max. 250v |
max.1 |
pse, ek |
260℃ |
220℃ |
350℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
240℃ |
200℃ |
290℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
228℃ |
193℃ |
300℃ |
|
|
axial |
max. 250v |
max.1 |
pse, ek |
222℃ |
195℃ |
300℃ |
|
|
axial |
max. 250v |
max.1 |
vde, pse, ccc, ek |
216℃ |
191℃ |
241℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
192℃ |
162℃ |
290℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
184℃ |
160℃ |
300℃ |
|
|
axial |
max. 250v |
max.1 |
pse, ek |
179℃ |
155℃ |
300℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
170℃ |
146℃ |
300℃ |
|
|
axial |
max. 250v |
max.1 |
pse, ek |
169℃ |
145℃ |
300℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
167℃ |
142℃ |
250℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
152℃ |
128℃ |
250℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
144℃ |
120℃ |
250℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
141℃ |
117℃ |
171℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, pse, ek |
139℃ |
117℃ |
170℃ |
|
|
axial |
max. 250v |
max.1 |
pse |
132℃ |
110℃ |
155℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
128℃ |
106℃ |
155℃ |
|
|
axial |
max. 250v |
max.1 |
pse |
121℃ |
95℃ |
170℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
119℃ |
95℃ |
170℃ |
|
|
axial |
max. 250v |
max.1 |
pse |
115℃ |
95℃ |
170℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
110℃ |
88℃ |
140℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
104℃ |
80℃ |
150℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
100℃ |
78℃ |
250℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
98℃ |
76℃ |
140℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
91℃ |
67℃ |
135℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
84℃ |
60℃ |
125℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
77℃ |
55℃ |
120℃ |
|
|
axial |
max. 250v |
max.16a |
ul, cul, vde, pse, ccc, ek |
72℃ |
50℃ |
115℃ |
|
|
axial |
max. 250v |
max.1 |
ul, cul, vde, pse, ccc, ek |
66℃ |
42℃ |
130℃ |
temperature rise
temperature rising of tco shall be not more than 10℃, when the rated current to be passed through the tco.
